Semiconductors

Imagine Optic’s Semiconductor and Lithography solutions offer precise optical testing and qualification tools, essential for quality assurance and performance optimization in microchip production and advanced photolithography systems. Using patented metrology systems such as the Parallel Optics Procedure (POP) and leading wavefront sensors, Imagine Optic enables manufacturers to measure and analyze surface shape, transmitted and reflected wavefront errors, and minute aberrations across plane-parallel optics, lenses, and mirrors used in semiconductor fabrication.

With the MESO metrology instrument and HASO Shack–Hartmann wavefront sensors, users can accurately perform optical testing in reflection and transmission, qualifying each component’s surface figure and overall wavefront error—critical metrics for maintaining high yield and minimizing defects in semiconductor and lithography applications. These real-time measurement systems distinguish subtle defects, track Zernike coefficients to pinpoint specific aberrations, and support both alignment and optimization workflows on production lines and in R&D environments.

UV Laser Testing

For beam testing, collimation, beam pointing adjustment, alignment and aberration control of lasers and complete optical paths up to delivery, choose a compact, easy and quick to set up M2 or wavefront sensing solution combining live phase and intensity measurements.

RELATED PRODUCTS

MESO SWIR Metrology System
